23dBm Dual Band GSM Signal Booster GSM900MHz Dcs1800MHz Cell Phone Signal Amplifier Mobile Signal Repeater

Frequency RangeUplinkDownlink
GSM900+DCS1800890-915/1710-1785MHz935-960/1805-1880MHz
LTE26002500-2570MHz2620-2690MHz
CDMA 800/GSM 850824-849MHz869-894MHz
GSM 900890-915MHz935-960MHz
AWS17001710-1755MHz2110-2155MHz
DCS 18001710-1785MHz1805-1880MHz
PCS 19001850-1910MHz1930-1990MHz
WCDMA/3G 21001920-1980MHz2110-2170MHz
Gain70dB±2db75dB±2db
Output Power20dBm±2dbm23dBm±2dbm
BandwidthWide Band
Manual Gain Control31dB     / 1dB Step
Automatic Gain Control>20dB
Ripple in-band≤ 6dB
Return loss≤ -10dB
Noise Figure≤ 6dB
Spurious Emission
&Intermodulation
9KHz~1GHz≤ -36dBm
1~12.75GHz≤ -30dBm
WCDMASpurious Emission MaskMeet 3GPP TS 25.143 ( V 6.2.0 )
 Modulation Accuracy≤ 12.5%
 Peak Code Domain Error≤ -35dB@Spreading Factor 256
Time Delay≤ 1.5 μs
Frequency stability≤ 0.01ppm
MTBF> 50000 hours
Power SupplyAC100-240V,DC9V/5A
Power LEDPower indicator
Alarm LEDRedAutoexcitation or High Power
GreenStandard
Mechanical Specification
RF ConnectorN-Female
SwitchPower Switch\Manual Gain Control Switch
CoolingHeatsink Convection cooling
Impedance50 ohm
Humidity< 90%
Operating Temperature-10°C~55°C
Environment ConditionsIP40
Size250mm*170mm*53mm
Weight< 3.5Kg

Features:
1. Cost-effective solution for weak signal zones, reduce drop/off calls.
2. Compact size, low power consumption, easy installation, great cover.
Expansion and extension of the signal of the base station. Optimization of the quality of the signal and source
3. Cover about 500~2000m² Without block or obstruct.
4. High linear design, ALC function design, low interference to BTS.
5. Support any cellular devices (voice & data & video)
6. Wideband signal booster, or customize selective band booster.
7. Support System CDMA800, GSM, DCS, PCS, WCDMA, LTE 4G etc

Advantages:
1. Smart Function, Intelligent mode setting
smart function called which can be activated via the front panel.
users can adjust gain and choose working band by LED panel, This smart function is easier than DIP Switch, can set up parameters, It is a simple, safe, and effective way.
2. Auto Level Control
The 30dB ALC is used to maintain steady output power even when the donor source signal fluctuates.

Standard Package:
1) AC90-264V, DC9V/5A power supply adapter 1PCS
2) AC power cord (EU/US/UK/SA/China standard, etc) 1PCS
3) Installation kit 1PCS
4) User manual 1PCS

Recommended Accessories:
1) Donor antenna: Log Periodic Antenna (9dBi,806-960/1710-2700MHz)
2) Service antenna: Omni Ceiling Antenna (3dBi,806-960/1710-2700MHz)
3) 5D-FB coaxial cable with connecter (Cable length optional)

 Advantages:
1. Smart Function, Intelligent mode setting
smart function called which can be activated via the front panel.
users can adjust gain and choose working band by LED panel, This smart function is easier than DIP Switch, can set up parameters, It is a simple, safe, and effective way.
2. Auto Level Control
The 30dB ALC is used to maintain steady output power even when the donor source signal fluctuates.
23dBm Dual Band GSM Signal Booster GSM900MHz Dcs1800MHz Cell Phone Signal Amplifier Mobile Signal Repeater
Method of Installation:
The booster is fixed onto the wall through expansion bolts.
A.  Drill holes in the selected place and install expansion bolts.
B.  Align the holes with the expansion bolts, place flat washers, spring washers, and nuts in turn, and tighten the nuts to fasten the installing support.
C. Place the booster on and fasten it.
D. Connect cables and power cables to the booster respectively.
E. After installing the booster as described above, power on the booster to check the operation status.

Connection:
A.  BTS Port: donor antenna cable is connected with Outdoor Port;
B.  MS Port: service whip antenna is connected with Indoor Port;
C.  DC IN: connected with Power adaptor.
23dBm Dual Band GSM Signal Booster GSM900MHz Dcs1800MHz Cell Phone Signal Amplifier Mobile Signal Repeater
23dBm Dual Band GSM Signal Booster GSM900MHz Dcs1800MHz Cell Phone Signal Amplifier Mobile Signal Repeater
23dBm Dual Band GSM Signal Booster GSM900MHz Dcs1800MHz Cell Phone Signal Amplifier Mobile Signal Repeater
23dBm Dual Band GSM Signal Booster GSM900MHz Dcs1800MHz Cell Phone Signal Amplifier Mobile Signal Repeater

23dBm Dual Band GSM Signal Booster GSM900MHz Dcs1800MHz Cell Phone Signal Amplifier Mobile Signal Repeater
23dBm Dual Band GSM Signal Booster GSM900MHz Dcs1800MHz Cell Phone Signal Amplifier Mobile Signal Repeater

Q1. Could I get a sample before bulk order?

Yes, we offer the sample for all models but charged.

Q2. What should I do if I don't know about frequency in my country?

Please feel free to contact us with your inquiry, we will find the frequency you need and address your problems.

Q3. Do you accept OEM/ODM order?

Yes, we can customize the brand logo, colors, and frequencies.

Q4.Shipment Date

Sample3-5 business days
<20 pcs7-15 days
20-50 pcs15-24 days
>50 pcsNegotiate

Q5: Delivery Date of the sample by DHL/FedEx
USA/Canada/Europe/Asia3-5 days
Middle East/Latin American5-7 days
African3-7 days

Q6.Payment Method

T/T, Western Union, Paypal, and Credit Card are available,
but we suggest paying by Alibaba Trade Assurance, the most favor, and security method.
*Other methods please contact us with more details.

Q7.Others
(1)Frequency
We can customize Single/Double/Triple/Quand/Penta Band for cellphone signal like 2G/3G/4G(GSM/CDMA/DCS/PCS/WCDMA/LTE, etc,)
(2)Output Power &Coverage Areas

Output PowerCoverage Areas
20dBm500-1500m²
23dBm1500-2500m²
25dBm2500-4000m²
27dBm3000-5000m²
30dBm5000-8000m²

*Coverage is related to local signal strength, please contact us with your local condition, we can offer the best solution.
(3)Antenna
Cellphone signal booster must attach one indoor antenna and one outdoor antenna by two coaxial cables.
Website's price only includes a signal booster, please contact us if you need one set of devices with antenna, splitter, and coupler.
