Sunhans 3W 2400~2500MHz WiFi Wireless Extender 35dBm Signal Booster Amplifier with 6dBi Antenna IEEE 802.11b/g/n Supported
Features:
2.4GHz, Max. 3000mW output power;
Aluminum-alloy case by CNC, anti-interference;
Cost effective solution for weak signal zones, reduce drop/off calls;
Full kit, easy to install; light weight, small size, protable;
Designed for house, office, UAV, IP cameras, RC equipment....
Cell phone Amplifier Description: 3000mW 2.4Ghz 35dBm WiFi Signal Booster
Package contents:
All specifications of PA can be customized based on customer requirement.
Product Description:
The 2.4GHz WLAN signal booster is designed for IEEE 802.11b/g/n/a/ac Wireless LAN Applications.The product is compatible with time division duplexing (TDD) method of WLAN and using rapid microwave detection technology to provide high linearity amplification. The signal booster can work with most WLAN/Wi-Fi device and increase the WLAN signal strength, therefore a larger WLAN coverage and more stable transmission rate.
Application:
2.4GHz 3w 35dBm is Popular for UAV,Routers,IP cameras, R/C helicopters, planes and cars, Bluetooth, Walkie talkies,Robotics for beach and flood rescue;
For house, office,Hotels,supermarkets, Hospitals,parking spaces, office....
Solution: Hot Spot solutions,Access points,Smart home systems
1. What is the WiFi signal booster?
The working mode of the WiFi signal booster needs to be connected to the signal source (customer device which cause wifi signal ) through one end of the cable, and the other end is connected to the antenna, and the WiFi signal range is expanded through the antenna.
2. Can I install the Sunhans booster myself?
Of course, our products are easy to install and plug and play, and the product package contains instructions for each product.
About US
Our Service:
♦ Test process : every items will be testing before shipping, to make sure the quality.
♦ Short leading time: 1-2.5 working days for samples or small order, 10-15 working days for bulk order.
♦ One year warranty: for you without trouble of after-sales maintenance.
♦ Quality Guarantee: Return rate is only 0.001.
♦ Support small orders: help your business from small to big.
♦ OEM & ODM are welcome.
Features:
2.4GHz, Max. 3000mW output power;
Aluminum-alloy case by CNC, anti-interference;
Cost effective solution for weak signal zones, reduce drop/off calls;
Full kit, easy to install; light weight, small size, protable;
Designed for house, office, UAV, IP cameras, RC equipment....
Cell phone Amplifier Description: 3000mW 2.4Ghz 35dBm WiFi Signal Booster
| SKU | 0305SH100023 |
| Model | SH24BTANP |
| Operating Range | 2.4~2.5 GHz |
| Channel width | 20Mhz & 40Mhz |
| Supported standards | IEEE 802.11b/g/n |
| Operating Mode | Bi-directional, half-duplex, time division duplex |
| Connector type | To radio SMA female (hole inside). To antenna RP-SMA female (pin inside) |
| Input power | 0~20 dBm |
| Transmit gain | 15-18dB |
| Output Power | 3W (35dBm) |
| Receiver Gain | ≤ 12 dB |
| Noise Figure | ≤3.5 dB typical |
| Frequency Response | ±1dB over operating range |
| Connector type | N-K female |
| Power supply | 12V/2A DC, 100~240V |
| Operating Temperature | -20°C to + 70°C |
| Operating Humidity | Up to 75% relative humidity |
| Material | Cast Aluminum |
| Booster Size | 8.6 x 5.1 x 1.8cm |
| Booster Weight | 85g |
Package contents:
1 x SH24BTA-N WiFi booster
1 x RG316 cable with SMA connectors (20cm)
1 x 6dBi omni antenna
1 x power supply
1 x user manual
1 x RG316 cable with SMA connectors (20cm)
1 x 6dBi omni antenna
1 x power supply
1 x user manual
All specifications of PA can be customized based on customer requirement.
Product Description:
The 2.4GHz WLAN signal booster is designed for IEEE 802.11b/g/n/a/ac Wireless LAN Applications.The product is compatible with time division duplexing (TDD) method of WLAN and using rapid microwave detection technology to provide high linearity amplification. The signal booster can work with most WLAN/Wi-Fi device and increase the WLAN signal strength, therefore a larger WLAN coverage and more stable transmission rate.
Application:
2.4GHz 3w 35dBm is Popular for UAV,Routers,IP cameras, R/C helicopters, planes and cars, Bluetooth, Walkie talkies,Robotics for beach and flood rescue;
For house, office,Hotels,supermarkets, Hospitals,parking spaces, office....
Solution: Hot Spot solutions,Access points,Smart home systems
| Features: |
| 1. Easy Installation |
| 2. Plug and play, no software setup. |
| 3. 3.5dB ultra-low noise |
| 4. Aluminum-alloy case by CNC, it can expand wifi signal range 10-20 times. |
| 5. Can enlarge WiFi signal coverage range, as long as the frequency of the product can be applied |
| 6. Widely used in security, drones, urban hotspot coverage, railway hotspot coverage, etc. |
1. What is the WiFi signal booster?
The working mode of the WiFi signal booster needs to be connected to the signal source (customer device which cause wifi signal ) through one end of the cable, and the other end is connected to the antenna, and the WiFi signal range is expanded through the antenna.
2. Can I install the Sunhans booster myself?
Of course, our products are easy to install and plug and play, and the product package contains instructions for each product.
